- Part Number EBC06DRAS
- Manufacturer Sullins
- Pin Count 14
- Part Category Connector
- Package Category Other
- Footprint Name Other - EBC06DRAS-1
- Released Date Sep 23, 2021
- Last Modified Date Mar 7, 2023 4:10 PM UTC
- Pinout / Pin List Click Here (Member Only)
EBC06DRAS Details
-
Manufacturer Part Number:
EBC06DRAS
-
Pbfree Code:
Yes
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Active
-
ECCN Code:
EAR99
-
HTS Code:
8536.69.40.40
-
Manufacturer:
Sullins Connector Solutions
-
YTEOL:
6.75
-
Body Breadth:
0.33 inch
-
Body Depth:
0.637 inch
-
Body Length:
1.475 inch
EBC06DRAS Frequently Asked Questions (FAQs)
-
The recommended torque for the screws on the EBC06DRAS connector is 0.5-1.5 Nm (4-12 in-lbs). It's essential to follow the recommended torque to ensure proper connection and prevent damage to the connector.
-
Yes, the EBC06DRAS connector is designed to withstand high-vibration environments. However, it's crucial to ensure proper mounting and screw torque to maintain the connection's integrity. Additionally, consider using additional locking mechanisms or potting compounds to enhance the connector's reliability in extreme vibration conditions.
-
The EBC06DRAS connector has a rating of IP67, which means it can withstand temporary immersion in water and exposure to dust. However, for outdoor or harsh environmental applications, it's recommended to use additional protection measures such as conformal coating, potting, or sealing to ensure the connector's reliability and longevity.
-
The EBC06DRAS connector has an operating temperature range of -40°C to 105°C (-40°F to 221°F). However, it's essential to consider the temperature rating of the specific application and ensure the connector is used within its recommended operating range to maintain its performance and reliability.
-
The EBC06DRAS connector is designed to work with 20-24 AWG wire. While it may be possible to use a different wire gauge or type, it's crucial to ensure the wire meets the connector's specifications and is compatible with the application's requirements. Consult with Sullins Connector Solutions or a qualified engineer to determine the suitability of alternative wire configurations.
