EC3SMD-32-15.999MTR - Ecliptek

EC3SMD-32-15.999MTR Details

• Manufacturer Part Number:

  EC3SMD-32-15.999MTR

• Part Life Cycle Code:

  Obsolete

• Package Description:

  RESISTANCE WELD SEAL, SMD, 4 PIN

• HTS Code:

  8541.60.00.50

• Manufacturer:

  Ecliptek Corporation

• YTEOL:

  0

• Additional Feature:

  AT CUT; TAPE AND REEL

• Aging:

  5 PPM/YEAR

• Crystal/Resonator Type:

  PARALLEL - FUNDAMENTAL

• Drive Level:

  1000 µW

• Frequency Stability:

  0.005%

• Frequency Tolerance (MHz):

  30

• JESD-609 Code:

  e4

• Load Capacitance:

  32 pF

• Mounting Feature:

  SURFACE MOUNT

• Operating Frequency-Nom:

  15.999 MHz

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Packing Method:

  TR

• Physical Dimension:

  L12.5XB4.95XH4.0 (mm)/L0.492XB0.195XH0.157 (inch)

• Series Resistance:

  60 Ω

• Surface Mount:

  YES

• Terminal Finish:

  Silver (Ag)
