ECN3296TF - HITACHI

ECN3296TF Details

• Manufacturer Part Number:

  ECN3296TF

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  TQFP-48

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Hitachi Ltd

• Analog IC - Other Type:

  SPST

• JESD-30 Code:

  S-PQFP-G48

• Length:

  7 mm

• Number of Channels:

  1

• Number of Functions:

  16

• Number of Terminals:

  48

• Off-state Isolation-Nom:

  33 dB

• On-state Resistance Match-Nom:

  1.9 Ω

• On-state Resistance-Max (Ron):

  38 Ω

• Operating Temperature-Max:

  70 °C

• Output:

  SEPARATE OUTPUT

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  LFQFP

• Package Equivalence Code:

  QFP48,.35SQ,20

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK, LOW PROFILE, FINE PITCH

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  1.7 mm

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  3 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  YES

• Switch-off Time-Max:

  5000 ns

• Switch-on Time-Max:

  5000 ns

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Width:

  7 mm
