EDSP10SGLNNTU04 - TE Connectivity

EDSP10SGLNNTU04 Details

• Manufacturer Part Number:

  EDSP10SGLNNTU04

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  TE Connectivity

• YTEOL:

  5.8

• Actuator Color:

  WHITE

• Actuator Type:

  PIANO TYPE

• Body Height:

  5 mm

• Body Length or Diameter:

  25.3 mm

• Center Contact Plating:

  GOLD OVER NICKEL

• Contact Current(AC)-Max:

  0.025 A

• Contact Current(DC)-Max:

  0.025 A

• Contact Voltage(DC)-Max:

  24 V

• End Contact Material:

  COPPER ALLOY

• End Contact Plating:

  GOLD OVER NICKEL

• Housing Material:

  NYLON

• Mounting Feature:

  PANEL MOUNT

• Number of Positions:

  10

• Number of Switch Sections:

  10

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• Packing Method:

  TUBE

• Surface Mount:

  NO

• Switch Function:

  SPST

• Switch Type:

  PIANO DIP SWITCH
