The recommended torque for the screws on the EGBM-RA-20 is 1.5-2.5 in-lbs (0.17-0.28 Nm) according to Samtec's application notes.
Yes, the EGBM-RA-20 is designed to withstand high-vibration environments. Samtec recommends following their guidelines for vibration testing and ensuring proper screw torque to ensure reliable connections.
The EGBM-RA-20 has an operating temperature range of -55°C to +125°C, making it suitable for most industrial and commercial applications.
Yes, the EGBM-RA-20 is compatible with lead-free soldering processes. Samtec recommends following their recommended soldering profiles and guidelines for lead-free soldering.
The EGBM-RA-20 has a mating cycle life of 500 cycles minimum, making it suitable for applications that require frequent mating and unmating.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
EGBM-RA-20 Overview
Use the download button to access the EGBM-RA-20 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like EGBM-,
or try a keyword search, such as Assembly Items
