ELC18B220L footprint, schematic symbol and 3D model by Panasonic

Symbol

PCB Footprints

3D Models

ELC18B220L Details

The recommended land pattern for ELC18B220L is a rectangular pad with a size of 2.5mm x 1.5mm, with a solder mask clearance of 0.2mm. It's also recommended to have a via-in-pad design to reduce thermal resistance.
To handle the high self-resonant frequency of ELC18B220L, it's recommended to use a series resistor or a damping resistor to reduce the Q factor and prevent unwanted oscillations. Additionally, a shielded enclosure or a metal can package can help to reduce electromagnetic interference.
The maximum operating temperature range for ELC18B220L is -40°C to +125°C. However, it's recommended to derate the component's characteristics above 85°C to ensure reliable operation.
To ensure the reliability of ELC18B220L in high-vibration environments, it's recommended to use a secure mounting method such as screw mounting or adhesive bonding. Additionally, a conformal coating or potting compound can help to reduce the risk of mechanical damage.
The equivalent series resistance (ESR) of ELC18B220L is approximately 0.15 ohms at 100 kHz. However, the ESR can vary depending on the frequency and operating conditions, so it's recommended to consult the datasheet or contact Panasonic for more information.

Expert Contribution

System Verified

Community Approved

Use the download button to access the ELC18B220L schematic symbol, PCB footprint, and 3D model.

To find more CAD model downloads similar to this part, try a partial part number search, like ELC18, or try a keyword search, such as Fixed Inductors
