ADJUSTABLE OUTPUT MODE FROM 1.35 TO 3.6V; ALSO REQ SUPPLY PVIN 4.5 TO 16V
Analog IC - Other Type:
SWITCHING REGULATOR
Control Mode:
VOLTAGE-MODE
Control Technique:
PULSE WIDTH MODULATION
Input Voltage-Max:
5.25 V
Input Voltage-Min:
4.75 V
Input Voltage-Nom:
5 V
JESD-30 Code:
R-XXSS-N104
Length:
17 mm
Number of Functions:
1
Number of Terminals:
104
Operating Temperature-Max:
85 °C
Operating Temperature-Min:
-40 °C
Package Body Material:
UNSPECIFIED
Package Shape:
RECTANGULAR
Package Style:
SPECIAL SHAPE
Seated Height-Max:
6.91 mm
Surface Mount:
YES
Switcher Configuration:
BUCK
Switching Frequency-Max:
1333 kHz
Temperature Grade:
INDUSTRIAL
Terminal Form:
NO LEAD
Terminal Position:
UNSPECIFIED
Width:
11 mm
EM2130H01QI Frequently Asked Questions (FAQs)
Intel provides a reference design guide for the EM2130H01QI, which includes recommendations for PCB layout, thermal design, and component placement to ensure optimal performance and thermal management.
The EM2130H01QI requires a specific power sequencing and voltage regulation scheme. Intel provides a power management guide that outlines the recommended power-up and power-down sequences, as well as voltage regulator module (VRM) design guidelines.
The EM2130H01QI has a maximum junction temperature (Tj) of 100°C. Intel recommends using a heat sink with a thermal interface material (TIM) and ensuring good airflow to maintain a safe operating temperature. A thermal design guide is available from Intel to help with thermal management.
Intel provides a debugging guide for the EM2130H01QI, which includes information on error codes, signal integrity, and troubleshooting techniques. Additionally, Intel offers development tools and software to help engineers debug and optimize their designs.
The EM2130H01QI is designed to meet various EMC and EMI standards. Intel provides guidelines for PCB design, component selection, and shielding to minimize EMI and ensure EMC compliance.
