XP Power recommends a PCB layout with a large copper area connected to the tab of the device to dissipate heat effectively. A minimum of 1 oz copper thickness is recommended, and the copper area should be at least 1 inch x 1 inch in size.
Yes, the EML15US05-P is designed to withstand vibrations up to 10G peak acceleration, 10-2000 Hz frequency range, and 1 hour duration per axis. However, it's recommended to consult with XP Power's application engineers to ensure the module meets the specific vibration requirements of your application.
The maximum capacitance load that can be connected to the output of the EML15US05-P is 47μF. Exceeding this value may cause instability or oscillation in the output voltage.
The EML15US05-P is designed to operate up to 5,000 meters (16,400 feet) above sea level. However, the module's power rating may need to be de-rated at higher altitudes due to the lower air pressure and oxygen levels.
Yes, the EML15US05-P can be used in a redundant configuration to achieve higher reliability and availability. However, it's recommended to consult with XP Power's application engineers to ensure the correct implementation of the redundant configuration.
