EP6400-14 - PCA

EP6400-14 Details

• Manufacturer Part Number:

  EP6400-14

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active

• Part Package Code:

  DIP

• Package Description:

  DIP-14

• Pin Count:

  14

• Country Of Origin:

  Mainland China, Philippines

• HTS Code:

  8542.39.00.60

• Manufacturer:

  PCA Electronics Inc

• YTEOL:

  4

• Additional Feature:

  MAX RISE TIME CAPTURED

• Family:

  EP64

• JESD-30 Code:

  R-XDIP-T14

• JESD-609 Code:

  e0

• Length:

  19.304 mm

• Logic IC Type:

  PASSIVE DELAY LINE

• Moisture Sensitivity Level:

  3

• Number of Functions:

  1

• Number of Taps/Steps:

  10

• Number of Terminals:

  14

• Operating Temperature-Max:

  70 °C

• Output Impedance-Nom (Z0):

  500 Ω

• Output Polarity:

  TRUE

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DIP

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  225

• Programmable Delay Line:

  NO

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  5.842 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  COMMERCIAL

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Total Delay-Nom (td):

  250 ns

• Width:

  7.62 mm
