EPC1PC8 - Intel

EPC1PC8 Details

• Manufacturer Part Number:

  EPC1PC8

• Part Life Cycle Code:

  Obsolete

• Package Description:

  DIP-8

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.61

• Manufacturer:

  Intel Corporation

• YTEOL:

  0

• Additional Feature:

  IT ALSO REQUIRES 5V NOMINAL SUPPLY

• JESD-30 Code:

  R-PDIP-T8

• JESD-609 Code:

  e0

• Length:

  9.398 mm

• Memory Density:

  1046496 bit

• Memory IC Type:

  CONFIGURATION MEMORY

• Memory Width:

  1

• Moisture Sensitivity Level:

  1

• Number of Functions:

  1

• Number of Terminals:

  8

• Number of Words:

  1046496 words

• Number of Words Code:

  1046496

• Operating Mode:

  SYNCHRONOUS

• Operating Temperature-Max:

  70 °C

• Organization:

  1046496X1

• Output Characteristics:

  3-STATE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  DIP8,.3

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Parallel/Serial:

  SERIAL

• Programming Voltage:

  3.3 V

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  4.318 mm

• Standby Current-Max:

  0.0001 A

• Supply Current-Max:

  0.05 mA

• Supply Voltage-Max (Vsup):

  3.6 V

• Supply Voltage-Min (Vsup):

  3 V

• Supply Voltage-Nom (Vsup):

  3.3 V

• Surface Mount:

  NO

• Technology:

  CMOS

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Width:

  7.62 mm
