EPC3472G - PCA Electronics, Inc.

EPC3472G Details

• Manufacturer Part Number:

  EPC3472G

• Part Life Cycle Code:

  Active

• Package Description:

  25W FLYBACK ISOLATED INDUCTOR

• Country Of Origin:

  Mainland China, Philippines

• ECCN Code:

  EAR99

• Manufacturer:

  PCA Electronics Inc

• YTEOL:

  5

• Additional Feature:

  HEIGHT DIM INCLUDE TERMINAL ALSO

• Height:

  11.51 mm

• Input Voltage-Max:

  57 V

• Input Voltage-Min:

  9 V

• JESD-609 Code:

  e0

• Length:

  23.01 mm

• Mounting Feature:

  SURFACE MOUNT

• Number of Primary Winding:

  2

• Number of Secondary Winding:

  2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Voltage 1:

  5 V

• Packing Method:

  TR

• Power Rating:

  25 W

• Primary Inductance:

  9 µH

• Surface Mount:

  YES

• Terminal Finish:

  TIN LEAD

• Transformer Type:

  SMPS TRANSFORMER

• Width:

  22 mm
