EPH2815 - Sumida

EPH2815 Details

• Manufacturer Part Number:

  EPH2815

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Sumida Corporation

• YTEOL:

  6

• Approvals:

  AEC-Q200

• Height:

  17 mm

• Input Voltage-Max:

  35 V

• Input Voltage-Min:

  20 V

• Length:

  28 mm

• Mounting Feature:

  THROUGH HOLE MOUNTED

• Number of Primary Winding:

  1

• Number of Secondary Winding:

  4

• Operating Frequency-Max:

  500 kHz

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Voltage 1:

  15 V

• Output Voltage 2:

  15 V

• Power Rating:

  25.6 W

• Primary Inductance:

  10 µH

• Surface Mount:

  NO

• Transformer Type:

  SMPS TRANSFORMER

• Width:

  28 mm
