EPS3PC2 - Switchcraft

EPS3PC2 Details

• Manufacturer Part Number:

  EPS3PC2

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.65

• Manufacturer:

  Switchcraft Conxall

• YTEOL:

  10

• Actuator Type:

  SCREW DRIVER SLOT

• Body Breadth:

  16.51 mm

• Body Height:

  16.28 mm

• Body Length or Diameter:

  24.21 mm

• Contact (AC) Max Rating R Load:

  10.1A@125VAC

• Contact Current(AC)-Max:

  10.1 A

• Contact Current(DC)-Max:

  10.1 A

• Contact (DC) Max Rating R Load:

  10.1A@125VDC

• Contact Voltage(AC)-Max:

  125 V

• Contact Voltage(DC)-Max:

  125 V

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -20 °C

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  DPDT

• Switch Type:

  TOGGLE SWITCH

• Terminal Finish:

  Silver (Ag)

• Termination Type:

  SOLDER
