ERM02A110 - Advanced Energy

ERM02A110 Details

• Manufacturer Part Number:

  ERM02A110

• Part Life Cycle Code:

  Active

• Package Description:

  DIP-6

• Country Of Origin:

  Hong Kong SAR

• ECCN Code:

  EAR99

• Factory Lead Time:

  14 Weeks

• Manufacturer:

  Advanced Energy Industries Inc

• YTEOL:

  5

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  IEC, EN, UL, C-UL, CE

• Efficiency (Main Output):

  82%

• Input Voltage-Max:

  160 V

• Input Voltage-Min:

  40 V

• JESD-30 Code:

  R-XDIP-P6

• Length:

  50.8 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  0.5%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  2 A

• Output Voltage-Nom:

  5 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DIP

• Package Equivalence Code:

  MODULE,6LEAD,.8

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Protections:

  OVER VOLTAGE, OVER CURRENT, OVER TEMPERATURE, SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.053025 Vrms

• Screening Level:

  IEC/EN/UL 62368-1/60950-1; EN 50155/45545-2

• Seated Height-Max:

  11.75 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  10 W

• Trim/Adjustable Output:

  YES

• Width:

  25.4 mm
