ES22MABE - LITTELFUSE

ES22MABE Details

• Manufacturer Part Number:

  ES22MABE

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Vietnam

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  7

• Actuator Color:

  BLACK

• Actuator Length:

  0.121 inch

• Actuator Type:

  SLIDE

• Additional Feature:

  ROHS COMPLIANT

• Body Breadth:

  9.14 mm

• Body Height:

  6.38 mm

• Body Length or Diameter:

  10.03 mm

• Center Contact Material:

  COPPER ALLOY

• Center Contact Plating:

  GOLD OVER NICKEL

• Contact (AC) Max Rating R Load:

  .02A@20VAC

• Contact Current(AC)-Max:

  0.02 A

• Contact Current(DC)-Max:

  0.02 A

• Contact (DC) Max Rating R Load:

  .02A@20VDC

• Contact Function:

  OFF-ON

• Contact Resistance:

  0.05 mΩ

• Contact Voltage(AC)-Max:

  20 V

• Contact Voltage(DC)-Max:

  20 V

• Dielectric Withstand Volts:

  500VRMS V

• Electrical Life:

  40000 Cycle(s)

• End Contact Material:

  BRONZE

• End Contact Plating:

  GOLD OVER NICKEL

• Housing Material:

  NYLON

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  NYLON

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Number of Positions:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -30 °C

• PCB Hole Count:

  6

• Packing Method:

  ANTI-STATIC TRAY

• Sealing:

  EPOXY TERMINAL SEALED; IP57

• Solderability:

  MIL-STD

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  DPST

• Switch Type:

  SLIDE SWITCH

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier

• Terminal Length:

  0.3 inch

• Terminal Material:

  COPPER ALLOY

• Termination Type:

  SOLDER
