ESD188B1W0201E6327XTSA1 - Infineon

ESD188B1W0201E6327XTSA1 Details

• Manufacturer Part Number:

  ESD188B1W0201E6327XTSA1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Germany, Malaysia

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  6

• Additional Feature:

  LOW CAPACITANCE

• Breakdown Voltage-Nom:

  1.1 V

• Clamping Voltage-Max:

  4.5 V

• Configuration:

  SINGLE, 1 CHANNEL

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  R-XBCC-N2

• Non-rep Peak Rev Power Dis-Max:

  22.5 W

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  UNSPECIFIED

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER

• Packing Method:

  TR

• Polarity:

  BIDIRECTIONAL

• Reference Standard:

  IEC-61000-4-2, 4-4, 4-5

• Rep Pk Reverse Voltage-Max:

  1 V

• Reverse Current-Max:

  40 µA

• Reverse Test Voltage:

  1.1 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Form:

  NO LEAD

• Terminal Position:

  BOTTOM
