ETQP5M470YFK - Panasonic

ETQP5M470YFK Details

• Manufacturer Part Number:

  ETQP5M470YFK

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• Country Of Origin:

  Japan

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Factory Lead Time:

  23 Weeks

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  7

• Case/Size Code:

  3331

• Construction:

  Rectangular

• Core Material:

  METAL COMPOSITE

• DC Resistance:

  0.138 Ω

• Inductance-Nom (L):

  48 µH

• Inductor Application:

  POWER INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -40 °C

• Package Height:

  5.4 mm

• Package Length:

  8.5 mm

• Package Style:

  SMT

• Package Width:

  8 mm

• Packing Method:

  TR, Embossed , 13 Inch

• Rated Current-Max:

  3.4 A

• Reference Standard:

  AEC-Q200

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  YES

• Special Feature:

  DCR IS MEASURED AT 10% TOLERANCE

• Surface Mount:

  YES

• Terminal Placement:

  DUAL ENDED

• Terminal Shape:

  WRAPAROUND

• Test Frequency:

  0.1 MHz

• Tolerance:

  20%
