EVQQ1E06K - Panasonic

EVQQ1E06K Details

• Manufacturer Part Number:

  EVQQ1E06K

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  End Of Life

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.40

• Factory Lead Time:

  10 Weeks

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  1

• Actuator Color:

  BLACK

• Actuator Travel:

  1 mm

• Actuator Type:

  PUSHBUTTON

• Body Breadth:

  8.5 mm

• Body Color:

  BLACK

• Body Height:

  5.1 mm

• Body Length or Diameter:

  8.5 mm

• Circuit Configuration:

  1X1

• Contact Bounce Time-Max:

  10 ms

• Contact Current(DC)-Max:

  0.05 A

• Contact (DC) Max Rating R Load:

  .05A@12VDC

• Contact Resistance:

  0.1 mΩ

• Contact Voltage(DC)-Max:

  12 V

• Dielectric Withstand Volts:

  250VAC V

• Electrical Life:

  100000 Cycle(s)

• Insulation Resistance:

  100000000 Ω

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Number of Switches:

  1

• Operating Force-Max:

  5 N

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX; TAPE AND REEL

• Sealing:

  DUST PROOF

• Solderability:

  REFLOW

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPST

• Switch Type:

  KEYPAD SWITCH

• Termination Type:

  SOLDER
