The recommended torque is 0.5 N·m to 1.5 N·m (5 to 15 lbf·in) for the M2 screws.
Yes, the EX80-54S(30) connector is designed to withstand vibrations and is suitable for use in high-vibration environments.
The operating temperature range for the EX80-54S(30) connector is -40°C to 105°C (-40°F to 221°F).
Yes, the EX80-54S(30) connector is compatible with lead-free soldering and is RoHS compliant.
The mating cycle rating for the EX80-54S(30) connector is 500 cycles.
Trust Checks
This model has been provided by an expert contributor.
Expert Contribution
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
EX80-54S(30) Overview
Use the download button to access the EX80-54S(30) schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like EX80-,
or try a keyword search, such as Telecom and Datacom Connectors
