EZPQ33305LTA - Panasonic

EZPQ33305LTA Details

• Manufacturer Part Number:

  EZPQ33305LTA

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  RADIAL LEADED

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8532.25.00.70

• Manufacturer:

  Panasonic Electronic Components

• YTEOL:

  7

• Additional Feature:

  ESR IS MEASURED AT 10KHZ, RIPPLE CURRENT IS MEASURED AT 10KHZ AND 85CEL

• Capacitance:

  3 µF

• Capacitor Type:

  FILM CAPACITOR

• Dielectric Material:

  POLYPROPYLENE

• ESR:

  23 mΩ

• Height:

  34.5 mm

• Length:

  41.5 mm

• Mounting Feature:

  THROUGH HOLE MOUNT

• Negative Tolerance:

  5%

• Number of Terminals:

  2

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Package Style:

  Radial

• Positive Tolerance:

  5%

• Rated (AC) Voltage (URac):

  330 V

• Ripple Current:

  5000 mA

• Surface Mount:

  NO

• Terminal Pitch:

  37.5 mm

• Terminal Shape:

  WIRE

• Width:

  17 mm
