F36-550 - Triad Magnetics

F36-550 Details

• Manufacturer Part Number:

  F36-550

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• HTS Code:

  8504.31.40.35

• Manufacturer:

  Triad Magnetics

• YTEOL:

  5.83

• Application:

  POWER

• Approvals:

  CUL; UL

• Center Tap Feature 1:

  NO

• Center Tap Feature 2:

  NO

• Height:

  36.51 mm

• Input Voltage-Nom:

  115 V

• Isolation Voltage:

  1500 V

• Length:

  57.15 mm

• Mounting Feature:

  THROUGH HOLE MOUNTED

• Number of Primary Winding:

  1

• Number of Secondary Winding:

  2

• Output Current 1:

  1.1 A

• Output Voltage 1:

  18 V

• Output Voltage 2:

  18 V

• Primary Rating:

  SINGLE 115V

• Surface Mount:

  NO

• Transformer Type:

  SPLIT BOBBIN POWER TRANSFORMER

• VA Rating:

  20 VA

• Width:

  47.63 mm
