F8UEE01A - LITTELFUSE

F8UEE01A Details

• Manufacturer Part Number:

  F8UEE01A

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• Country Of Origin:

  Vietnam

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.33

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  9

• Actuator Material:

  POLYESTER

• Actuator Type:

  PUSHBUTTON

• Body Breadth:

  9 mm

• Body Height:

  6.9 mm

• Body Length or Diameter:

  57 mm

• Center Contact Material:

  BRASS

• Center Contact Plating:

  SILVER

• Contact (AC) Max Rating R Load:

  0.5A@125VAC

• Contact Current(AC)-Max:

  0.5 A

• Contact Current(DC)-Max:

  0.5 A

• Contact (DC) Max Rating R Load:

  0.5A@30VDC

• Contact Resistance:

  0.02 mΩ

• Contact Timing:

  BREAK-BEFORE-MAKE

• Contact Voltage(AC)-Max:

  125 V

• Contact Voltage(DC)-Max:

  30 V

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  BRASS

• End Contact Plating:

  SILVER

• Housing Material:

  POLYCARBONATE

• Illumination:

  NON-ILLUMINATED

• Insulation Resistance:

  1000000000 Ω

• JESD-609 Code:

  e4

• Mounting Feature:

  PANEL MOUNT

• Operating Force-Max:

  9 N

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Sealing:

  TOP AND BOTTOM SEALED

• Surface Mount:

  NO

• Switch Action:

  ALTERNATE

• Switch Function:

  8PDT

• Switch Type:

  PUSHBUTTON SWITCH

• Terminal Finish:

  SILVER

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
