FA2786-BLB - COILCRAFT

FA2786-BLB Details

• Manufacturer Part Number:

  FA2786-BLB

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  CHIP

• ECCN Code:

  EAR99

• Manufacturer:

  Coilcraft Inc

• YTEOL:

  0

• Additional Feature:

  HEIGHT AND LENGTH DIMENSION INCLUDES TERMINAL ALSO

• Height:

  7.87 mm

• Input Voltage-Max:

  20 V

• Input Voltage-Min:

  8 V

• Length:

  24.51 mm

• Mounting Feature:

  SURFACE MOUNT

• Number of Primary Winding:

  1

• Number of Secondary Winding:

  1

• Operating Frequency-Max:

  100 kHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  TR

• Power Rating:

  6 W

• Primary Inductance:

  160 µH

• Surface Mount:

  YES

• Terminal Finish:

  Tin/Silver - Tin - with Nickel barrier

• Transformer Type:

  SMPS TRANSFORMER

• Width:

  15.49 mm
