FAM65CR51XZ1 - onsemi

FAM65CR51XZ1 Details

• Manufacturer Part Number:

  FAM65CR51XZ1

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  APMCD-A16 / 12LD, AUTOMOTIVE MODULE

• Package Description:

  ZIP-20/12

• Manufacturer Package Code:

  MODGG

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  onsemi

• Analog IC - Other Type:

  POWER FACTOR CONTROLLER

• JESD-30 Code:

  R-XZFM-T12

• Length:

  40.1 mm

• Number of Functions:

  1

• Number of Terminals:

  12

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  ZIP

• Package Equivalence Code:

  ZIP12/20,.1,.08,70TB

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Screening Level:

  AEC-Q101

• Seated Height-Max:

  4.7 mm

• Surface Mount:

  NO

• Switcher Configuration:

  BOOST

• Technology:

  HYBRID

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  1.778 mm

• Terminal Position:

  ZIG-ZAG

• Width:

  21.9 mm
