FCA-410-1620M - TE Connectivity

FCA-410-1620M Details

• Manufacturer Part Number:

  FCA-410-1620M

• Brand Name:

  CII

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  TE Connectivity

• YTEOL:

  6

• Body Breadth:

  26.03 mm

• Body Height:

  25.65 mm

• Body Length or Diameter:

  26.03 mm

• Coil Operate Voltage(DC):

  18 V

• Coil Release Voltage(DC):

  1.5 V

• Coil Resistance:

  290 Ω

• Coil Voltage(DC)-Max:

  28 V

• Coil Voltage-Nom:

  28 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  10A@120VAC

• Contact Current(AC)-Max:

  10 A

• Contact Current(DC)-Max:

  10 A

• Contact (DC) Max Rating R Load:

  10A@28VDC

• Contact Resistance:

  10 mΩ

• Contact Voltage(AC)-Max:

  120 V

• Contact Voltage(DC)-Max:

  28 V

• Contact/Output Supply Type:

  AC/DC

• End Contact Material:

  SILVER CADMIUM OXIDE

• End Contact Plating:

  GOLD

• Input Switching Control Type:

  Random

• Insulation Resistance:

  100000000 Ω

• JESD-609 Code:

  e0

• Mounting Feature:

  PANEL MOUNT

• Operate Time:

  15 ms

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -70 °C

• Physical Dimension:

  26.03mm x 26.03mm x 25.65mm

• Relay Action:

  MOMENTARY

• Relay Form:

  4 FORM C

• Relay Function:

  4PDT-CO

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  15 ms

• Sealing:

  HERMETICALLY SEALED

• Surface Mount:

  NO

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Length:

  0.006799593599187199 inch

• Termination Type:

  SOLDER HOOK
