FCB-405-BZ2 - TE Connectivity

FCB-405-BZ2 Details

• Manufacturer Part Number:

  FCB-405-BZ2

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Factory Lead Time:

  61 Weeks, 2 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  6.69

• Additional Feature:

  POLARIZED

• Body Breadth:

  20.37 mm

• Body Height:

  16.26 mm

• Body Length or Diameter:

  20.37 mm

• Coil Current(DC)-Max:

  0.12 A

• Coil Operate Voltage(DC):

  9 V

• Coil Power:

  1440 mW

• Coil Release Voltage(DC):

  0.75 V

• Coil Resistance:

  100 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  5A@115VAC

• Contact Current(AC)-Max:

  5 A

• Contact Current(DC)-Max:

  5 A

• Contact (DC) Max Rating R Load:

  5A@28VDC

• Contact Voltage(AC)-Max:

  115 V

• Contact Voltage(DC)-Max:

  28 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  SILVER CADMIUM OXIDE

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  7 ms

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -70 °C

• Physical Dimension:

  20.37mm x 20.37mm x 16.26mm

• Reference Standard:

  MIL-R-83536

• Relay Action:

  MOMENTARY

• Relay Form:

  4 FORM C

• Relay Function:

  4PDT-CO

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  7 ms

• Sealing:

  HERMETICALLY SEALED

• Surface Mount:

  NO

• Termination Type:

  SOLDER/QUICK CONNECT
