FFSM0465A - onsemi

FFSM0465A Details

• Manufacturer Part Number:

  FFSM0465A

• Brand Name:

  onsemi

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  PQFN-4

• Package Description:

  QFN-5

• Manufacturer Package Code:

  483AP

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Manufacturer:

  onsemi

• YTEOL:

  6

• Additional Feature:

  HIGH RELIABILITY, PD-CASE

• Application:

  EFFICIENCY

• Case Connection:

  CATHODE

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON CARBIDE

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  1.75 V

• JESD-30 Code:

  S-PSSO-N4

• Moisture Sensitivity Level:

  1

• Non-rep Pk Forward Current-Max:

  21 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  4

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  5.7 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Power Dissipation-Max:

  43 W

• Rep Pk Reverse Voltage-Max:

  650 V

• Reverse Current-Max:

  200 µA

• Reverse Test Voltage:

  650 V

• Surface Mount:

  YES

• Technology:

  SCHOTTKY

• Terminal Form:

  NO LEAD

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  30
