FH29DJ-120S-0.2SHW(05) Frequently Asked Questions (FAQs)

• What is the recommended torque value for the screw locks?
  The recommended torque value is 0.5 N·m to 1.5 N·m, but it's recommended to consult the datasheet or contact Hirose Electric Co Ltd for specific guidance.
• Can I use this connector in high-vibration environments?
  Yes, the FH29DJ-120S-0.2SHW(05) is designed to withstand vibrations and is suitable for use in harsh environments. However, it's essential to follow the recommended mounting and screw torque guidelines to ensure reliable operation.
• What is the maximum operating temperature range for this connector?
  The operating temperature range for the FH29DJ-120S-0.2SHW(05) is -40°C to 105°C. However, it's recommended to consult the datasheet or contact Hirose Electric Co Ltd for specific guidance on temperature-related derating.
• Is this connector compatible with automated assembly and reflow soldering processes?
  Yes, the FH29DJ-120S-0.2SHW(05) is designed to be compatible with automated assembly and reflow soldering processes. However, it's recommended to follow the recommended soldering profile and guidelines to ensure reliable operation.
• What is the recommended wire size and type for this connector?
  The recommended wire size is AWG 28-20, and the recommended wire type is a stranded wire with a conductor material of copper or copper alloy. However, it's recommended to consult the datasheet or contact Hirose Electric Co Ltd for specific guidance on wire selection.
