FHP-15-02-H-S-LC - SAMTEC

FHP-15-02-H-S-LC Details

• Manufacturer Part Number:

  FHP-15-02-H-S-LC

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Direct Group:

  CH551202070006YY0308008YY10011302

• Similar Group:

  CH551202070006YY0308008YY10

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  Samtec Inc

• YTEOL:

  9

• Body Breadth:

  0.2 inch

• Body Depth:

  0.368 inch

• Body Length:

  2.34 inch

• Connector Type:

  RECTANGULAR POWER CONNECTOR

• Contact Arrangement:

  S0P15

• Contact Finish Mating:

  AU

• Contact Finish Termination:

  Gold (Au) - with Nickel (Ni) barrier

• Contact Gender:

  FEMALE

• Contact Material:

  BERYLLIUM COPPER

• Contact Style:

  SQ PIN-SKT

• Insertion Force-Max:

  15.568 N

• Insulator Color:

  BLACK

• Insulator Material:

  LIQUID CRYSTAL POLYMER

• JESD-609 Code:

  e4

• Mixed Contacts:

  YES

• Mounting Option 1:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -55 °C

• Plating Thickness:

  30u inch

• Termination Type:

  SURFACE MOUNT

• Total Number of Contacts:

  15

• Withdrawl Force-Min:

  14.6784 N
