FL2015-3LB - COILCRAFT

FL2015-3LB Details

• Manufacturer Part Number:

  FL2015-3LB

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• Manufacturer:

  Coilcraft Inc

• YTEOL:

  0

• Additional Feature:

  LENGTH AND HEIGHT DIMENSION INCLUDES TERMINALS ALSO

• Height:

  7.87 mm

• Input Voltage-Max:

  16 V

• JESD-609 Code:

  e2

• Length:

  24.51 mm

• Mounting Feature:

  SURFACE MOUNT

• Number of Primary Winding:

  1

• Number of Secondary Winding:

  1

• Operating Frequency-Max:

  100 kHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Voltage 1:

  1600 V

• Packing Method:

  TR

• Power Rating:

  6 W

• Primary Inductance:

  19 µH

• Surface Mount:

  YES

• Terminal Finish:

  Tin/Silver (Sn/Ag)

• Transformer Type:

  SMPS TRANSFORMER

• Width:

  15.49 mm
