FL2015-7 - COILCRAFT

FL2015-7 Details

• Manufacturer Part Number:

  FL2015-7

• Pbfree Code:

  No

• Part Life Cycle Code:

  Obsolete

• ECCN Code:

  EAR99

• Manufacturer:

  Coilcraft Inc

• YTEOL:

  0

• Additional Feature:

  TURNS RATIO: 67:1

• Height:

  7.87 mm

• Input Voltage-Max:

  23 V

• Length:

  24.51 mm

• Mounting Feature:

  THROUGH HOLE MOUNTED

• Number of Primary Winding:

  2

• Number of Secondary Winding:

  1

• Operating Frequency-Max:

  100 kHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Voltage 1:

  1600 V

• Packing Method:

  TAPE & REEL

• Power Rating:

  6 W

• Primary Inductance:

  50 µH

• Surface Mount:

  NO

• Transformer Type:

  SMPS TRANSFORMER

• Width:

  15.24 mm
