FM22LD16-55-BG - RAMTRON

FM22LD16-55-BG Details

• Manufacturer Part Number:

  FM22LD16-55-BG

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Part Package Code:

  BGA

• Package Description:

  FBGA-48

• Pin Count:

  48

• Manufacturer:

  Ramtron International Corporation

• Access Time-Max:

  110 ns

• Additional Feature:

  DATA RETENTION TIME @ 85 DEGREE CENTIGRADE

• Data Retention Time-Min:

  10

• Endurance:

  100000000000000 Write/Erase Cycles

• JESD-30 Code:

  R-PBGA-B48

• Length:

  8 mm

• Memory Density:

  4194304 bit

• Memory IC Type:

  FRAM

• Memory Width:

  16

• Number of Functions:

  1

• Number of Terminals:

  48

• Number of Words:

  262144 words

• Number of Words Code:

  256000

• Operating Mode:

  ASYNCHRONOUS

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  256KX16

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TFBGA

• Package Equivalence Code:

  BGA48,6X8,30

• Package Shape:

  RECTANGULAR

• Package Style:

  GRID ARRAY, THIN PROFILE, FINE PITCH

• Parallel/Serial:

  PARALLEL

• Seated Height-Max:

  1.2 mm

• Standby Current-Max:

  0.00027 A

• Standby Voltage-Min:

  2.7 V

• Supply Current-Max:

  0.012 mA

• Supply Voltage-Max (Vsup):

  3.6 V

• Supply Voltage-Min (Vsup):

  2.7 V

• Supply Voltage-Nom (Vsup):

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  BALL

• Terminal Pitch:

  0.75 mm

• Terminal Position:

  BOTTOM

• Width:

  6 mm
