FM4-NDSP-PCB-1 - Amphenol

FM4-NDSP-PCB-1 Details

• Manufacturer Part Number:

  FM4-NDSP-PCB-1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.10

• Factory Lead Time:

  10 Weeks

• Manufacturer:

  Amphenol Corporation

• YTEOL:

  7

• Body Breadth:

  0.472 inch

• Body Depth:

  0.565 inch

• Body Length:

  0.593 inch

• Body/Shell Style:

  PLUG

• Characteristic Impedance:

  50 Ω

• Connector Type:

  RF SMB CONNECTOR

• Contact Finish Termination:

  Matte Tin (Sn)

• Contact Gender:

  MALE

• Contact Resistance:

  5 mΩ

• Contact Style:

  COAX

• Coupling Type:

  SNAP

• Dielectric Withstanding Voltage:

  750VAC V

• Durability:

  25 Cycles

• Filter Feature:

  NO

• Insulator Material:

  LIQUID CRYSTAL POLYMER

• JESD-609 Code:

  e3

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number of Ports:

  4

• Operating Frequency-Max:

  9 GHz

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Rated Current (Signal):

  2 A

• Shell Finish:

  TIN

• Shell Material:

  ZINC ALLOY

• Terminal Length:

  0.083 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  2

• VSWR:

  1.67
