FP24-1000 - Triad Magnetics

FP24-1000 Details

• Manufacturer Part Number:

  FP24-1000

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• HTS Code:

  8504.31.40.35

• Manufacturer:

  Triad Magnetics

• YTEOL:

  5.83

• Additional Feature:

  PCB MOUNTABLE

• Application:

  POWER

• Approvals:

  UL

• Center Tap Feature 1:

  NO

• Center Tap Feature 2:

  NO

• Height:

  34.92 mm

• Input Voltage-Nom:

  230 V

• Isolation Voltage:

  2000 V

• Length:

  72.9 mm

• Mounting Feature:

  THROUGH HOLE MOUNTED

• Number of Primary Winding:

  2

• Number of Secondary Winding:

  2

• Output Current 1:

  2 A

• Output Current 2:

  2 A

• Output Voltage 1:

  12 V

• Output Voltage 2:

  12 V

• Primary Rating:

  DUAL 115/230V

• Surface Mount:

  NO

• Transformer Type:

  SPLIT BOBBIN POWER TRANSFORMER

• VA Rating:

  24 VA

• Width:

  57.15 mm
