FP24-500 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal performance?
  Triad Magnetics recommends a symmetrical PCB layout with the transformer centered on the board, and the primary and secondary windings on opposite sides of the board to minimize electromagnetic interference (EMI).
• Can I use the FP24-500 in a high-temperature environment?
  While the FP24-500 is rated for operation up to 130°C, Triad Magnetics recommends derating the transformer's power handling by 1.5% per degree Celsius above 100°C to ensure reliable operation in high-temperature environments.
• How do I ensure proper creepage and clearance distances around the transformer?
  Triad Magnetics recommends maintaining a minimum creepage distance of 3.2 mm and a minimum clearance distance of 2.5 mm around the transformer to ensure safe and reliable operation.
• Can I use the FP24-500 in a DC-DC converter application?
  Yes, the FP24-500 can be used in DC-DC converter applications, but Triad Magnetics recommends consulting with their application engineers to ensure the transformer is properly specified and designed for the specific application.
• What is the recommended wire gauge and insulation for the primary and secondary windings?
  Triad Magnetics recommends using a minimum wire gauge of 20 AWG for the primary winding and 22 AWG for the secondary winding, with a minimum insulation rating of 150°C.
