FPC-96212-2211 - Yamaichi

FPC-96212-2211 Details

• Manufacturer Part Number:

  FPC-96212-2211

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• Manufacturer:

  Yamaichi Electronics Co Ltd

• Additional Feature:

  TUBE PACKAGING, TOP CONTACT

• Body Breadth:

  0.118 inch

• Body Depth:

  0.213 inch

• Body Length:

  1.142 inch

• Connector Type:

  FFC/FPC CONNECTOR

• Contact Finish Mating:

  SN

• Contact Material:

  PHOSPHOR BRONZE

• Contact Pattern:

  RECTANGULAR

• Contact Resistance:

  20 mΩ

• Contact Style:

  BELLOWED TYPE

• Dielectric Withstanding Voltage:

  500VAC V

• Filter Feature:

  NO

• Insertion Force-Max:

  ZIF N

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  POLYPHENYLENE SULFIDE

• Mating Contact Pitch:

  0.039 inch

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING MECH

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  1

• Number of Rows Loaded:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• PCB Contact Pattern:

  RECTANGULAR

• Rated Current (Signal):

  1 A

• Reference Standard:

  UL

• Terminal Pitch:

  0.9906 mm

• Termination Type:

  SURFACE MOUNT

• Total Number of Contacts:

  22
