TDK recommends a symmetrical PCB layout with a solid ground plane, and keeping the input and output traces as short as possible to minimize parasitic inductance and capacitance. A 4-layer PCB with a dedicated power plane and a solid ground plane is also recommended.
To ensure reliability in high-temperature applications, it's essential to follow TDK's recommended derating guidelines for temperature, voltage, and current. Additionally, ensure proper thermal management, such as using a heat sink or thermal interface material, and avoid exceeding the maximum operating temperature of 125°C.
The maximum allowable voltage stress on the FS1404-2500-AS is 2500Vrms for 1 minute, as per the IEC 61000-4-5 standard. However, it's recommended to follow the derating guidelines provided in the datasheet to ensure reliable operation.
Yes, the FS1404-2500-AS can be used in a redundant or parallel configuration, but it's essential to follow TDK's guidelines for paralleling or redundancy to ensure reliable operation and to avoid any potential issues with current sharing or voltage imbalance.
The typical lead time and MOQ for the FS1404-2500-AS may vary depending on the region, distributor, and availability. It's recommended to check with authorized distributors or TDK's sales representatives for the most up-to-date information on lead time and MOQ.
