TDK recommends a symmetrical layout with the component placed at the center of the PCB, and a solid ground plane on the bottom layer to minimize electromagnetic interference (EMI).
To ensure reliability, TDK recommends operating the FS1404-3300-AS within the specified temperature range (-40°C to +125°C), and using a suitable thermal interface material to maintain a low thermal resistance between the component and the PCB.
According to TDK, the maximum allowable voltage derating for the FS1404-3300-AS is 10% of the rated voltage, but this may vary depending on the specific application and operating conditions.
While the FS1404-3300-AS is designed for high-frequency applications, TDK recommends using it up to 500 MHz. For applications above 1 GHz, TDK recommends using a different component specifically designed for high-frequency applications.
TDK recommends storing the FS1404-3300-AS in its original packaging, away from direct sunlight, moisture, and extreme temperatures. During shipping, the component should be protected from mechanical stress, vibration, and electrostatic discharge (ESD).
