FS1406-0800-AL - TDK

FS1406-0800-AL Details

• Manufacturer Part Number:

  FS1406-0800-AL

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Factory Lead Time:

  10 Weeks

• Manufacturer:

  TDK Corporation

• Additional Feature:

  INPUT VOLTAGE RANGE FOR SINGLE SUPPLY IS 4.5 TO 16 V

• Analog IC - Other Type:

  SWITCHING REGULATOR

• Control Technique:

  PULSE WIDTH MODULATION

• Input Voltage-Max:

  16 V

• Input Voltage-Min:

  2.5 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  S-XBCC-N17

• Length:

  3.3 mm

• Number of Functions:

  1

• Number of Terminals:

  17

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  6 A

• Output Voltage-Max:

  2.5 V

• Output Voltage-Min:

  0.6 V

• Output Voltage-Nom:

  0.8 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  BCC

• Package Equivalence Code:

  LCC17,.13SQ,(UNSPEC)

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER

• Seated Height-Max:

  1.62 mm

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  YES

• Switcher Configuration:

  BUCK

• Terminal Form:

  NO LEAD

• Terminal Position:

  BOTTOM

• Width:

  3.3 mm
