FS24-1500 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal performance?
  Triad Magnetics recommends a symmetrical PCB layout with the transformer centered on the board, and the primary and secondary windings on opposite sides of the board to minimize electromagnetic interference (EMI).
• Can I use the FS24-1500 in a high-temperature environment?
  The FS24-1500 is rated for operation up to 130°C, but derating is required above 100°C. Consult the datasheet for derating curves and ensure proper thermal management to prevent overheating.
• How do I ensure proper insulation and creepage distance in my design?
  Follow the recommended creepage distance of 3.2 mm (0.125 in) between the primary and secondary windings, and ensure that the transformer is properly insulated from the PCB and other components.
• What is the recommended wire gauge for the primary and secondary windings?
  Triad Magnetics recommends using 18 AWG wire for the primary winding and 20 AWG wire for the secondary winding, but the specific gauge may vary depending on the application and current requirements.
• Can I use the FS24-1500 in a high-vibration environment?
  The FS24-1500 is designed to withstand moderate vibration, but extreme vibration may affect its performance and reliability. Consult Triad Magnetics for custom designs or modifications for high-vibration applications.
