FS28-200-C2 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout and spacing for optimal performance?
  Triad Magnetics recommends a minimum of 0.25 inches (6.4 mm) spacing between the transformer and other components, and a PCB layout that minimizes noise coupling and electromagnetic interference (EMI). A well-designed PCB layout can help reduce radiated emissions and improve the overall performance of the transformer.
• Can I use this transformer in a high-temperature environment?
  The FS28-200-C2 transformer is rated for operation up to 130°C, but derating may be necessary for temperatures above 100°C. It's essential to consult with Triad Magnetics or a qualified engineer to determine the suitable operating temperature range for your specific application.
• How do I ensure the transformer is properly secured to the PCB to prevent vibration and mechanical stress?
  Triad Magnetics recommends using a suitable adhesive, such as a thermally conductive epoxy, to secure the transformer to the PCB. Additionally, the PCB should be designed to minimize flexure and vibration, and the transformer should be oriented to minimize mechanical stress.
• What is the recommended wire gauge and insulation for the primary and secondary windings?
  Triad Magnetics recommends using a minimum of 18 AWG wire for the primary winding and 20 AWG wire for the secondary winding. The wire insulation should be rated for the maximum operating voltage and temperature of the application.
• Can I use this transformer in a high-humidity or moist environment?
  The FS28-200-C2 transformer is not hermetically sealed, so it's not suitable for use in high-humidity or moist environments. If your application requires operation in such conditions, you should consider using a transformer with a hermetic seal or conformal coating.
