FSMIJ61BPG04 - TE Connectivity

FSMIJ61BPG04 Details

• Manufacturer Part Number:

  FSMIJ61BPG04

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.40

• Factory Lead Time:

  6 Weeks, 6 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  9

• Actuator Color:

  BROWN

• Actuator Material:

  POLYAMIDE9T/POLYETHYLENE

• Actuator Travel:

  0.2 mm

• Actuator Type:

  RECTANGULAR TYPE

• Body Breadth:

  6.1 mm

• Body Color:

  BLACK

• Body Height:

  4.8 mm

• Body Length or Diameter:

  6.1 mm

• Center Contact Material:

  STAINLESS STEEL

• Center Contact Plating:

  SILVER

• Circuit Configuration:

  1X1

• Contact Current(AC)-Max:

  0.05 A

• Contact Current(DC)-Max:

  0.05 A

• Contact (DC) Max Rating R Load:

  0.05A@12VDC

• Contact Function:

  OFF-(ON)

• Contact Resistance:

  0.1 mΩ

• Contact Voltage(DC)-Max:

  12 V

• Dielectric Withstand Volts:

  250VAC V

• Electrical Life:

  500000 Cycle(s)

• End Contact Material:

  BRASS

• End Contact Plating:

  SILVER

• Housing Material:

  THERMOPLASTIC

• Illumination:

  GREEN LED

• Insulation Resistance:

  100000000 Ω

• Mounting Feature:

  PANEL MOUNT

• Number of Switches:

  1

• Operating Force-Max:

  0.98 N

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -25 °C

• Packing Method:

  BOX; TUBE

• Solderability:

  WAVE

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPST

• Switch Type:

  KEYPAD SWITCH

• Terminal Length:

  0.138 inch

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
