GAN039-650NTB - Nexperia

GAN039-650NTB Details

• Manufacturer Part Number:

  GAN039-650NTB

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SOT-8005, 12 PIN

• ECCN Code:

  EAR99

• Date Of Intro:

  2020-07-31

• Manufacturer:

  Nexperia

• YTEOL:

  7

• Case Connection:

  SOURCE

• Configuration:

  SINGLE WITH BUILT-IN MOSFET AND DIODE

• DS Breakdown Voltage-Min:

  650 V

• Drain Current-Max (ID):

  58.5 A

• Drain-source On Resistance-Max:

  0.039 Ω

• FET Technology:

  JUNCTION CASCODE

• Feedback Cap-Max (Crss):

  1.6 pF

• JESD-30 Code:

  R-PDSO-G12

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Number of Elements:

  1

• Number of Terminals:

  12

• Operating Mode:

  DEPLETION MODE

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  250 W

• Pulsed Drain Current-Max (IDM):

  234 A

• Reference Standard:

  IEC-60134

• Surface Mount:

  YES

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  40

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  GALLIUM NITRIDE
