GL823-OGGXX - Genesys

GL823-OGGXX Details

• Manufacturer Part Number:

  GL823-OGGXX

• Part Life Cycle Code:

  Contact Manufacturer

• Part Package Code:

  QFN

• Package Description:

  4 X 4 MM, GREEN, QFN-24

• Pin Count:

  24

• HTS Code:

  8542.31.00.30

• Manufacturer:

  Genesys Logic Inc

• Additional Feature:

  ALSO OPERATES AT 5 V NOMINAL

• JESD-30 Code:

  S-XQCC-N24

• JESD-609 Code:

  e4

• Length:

  4 mm

• Number of Terminals:

  24

• Operating Temperature-Max:

  70 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVQCCN

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Seated Height-Max:

  0.8 mm

• Supply Voltage-Max:

  3.46 V

• Supply Voltage-Min:

  3.14 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  COMMERCIAL

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  4 mm

• uPs/uCs/Peripheral ICs Type:

  MICROPROCESSOR CIRCUIT
