GRF1-P-P-04-E-ST-TH1 - SAMTEC

GRF1-P-P-04-E-ST-TH1 Details

• Manufacturer Part Number:

  GRF1-P-P-04-E-ST-TH1

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Factory Lead Time:

  1 Week

• Manufacturer:

  Samtec Inc

• Body Breadth:

  0.197 inch

• Body Depth:

  0.177 inch

• Body Length:

  0.788 inch

• Body/Shell Style:

  PLUG

• Characteristic Impedance:

  50 Ω

• Connector Type:

  RF CONNECTOR

• Contact Finish Mating:

  GOLD (50) OVER NICKEL (50)

• Contact Gender:

  MALE

• Contact Resistance:

  5 mΩ

• Contact Style:

  COAX

• Coupling Type:

  SNAP

• DIN Conformance:

  NO

• Dielectric Withstanding Voltage:

  700VAC V

• Filter Feature:

  NO

• IEC Conformance:

  NO

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  POLYTETRAFLUOROETHYLENE

• MIL Conformance:

  NO

• Mating Information:

  MULTIPLE MATING PARTS AVAILABLE

• Mounting Option 1:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number of Ports:

  4

• Operating Frequency-Max:

  6 GHz

• Operating Temperature-Max:

  90 °C

• Operating Temperature-Min:

  -40 °C

• Option:

  GENERAL PURPOSE

• Panel Mount:

  NO

• Rated Current (Signal):

  3.6 A

• Shell Material:

  BRASS

• Terminal Length:

  0.11 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  4
