GRF121R-5 - Teledyne Technologies

GRF121R-5 Details

• Manufacturer Part Number:

  GRF121R-5

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  Teledyne Technologies Inc

• YTEOL:

  9.2

• Additional Feature:

  SHIELDED

• Body Breadth:

  9.53 mm

• Body Height:

  9.78 mm

• Body Length or Diameter:

  12.96 mm

• Coil Current(DC)-Max:

  0.082 A

• Coil Operate Voltage(DC):

  4.3 V

• Coil Power:

  410 mW

• Coil Resistance:

  61 Ω

• Coil Voltage-Nom:

  5 V

• Coil/Input Supply Type:

  DC

• Contact Current(DC)-Max:

  0.25 A

• Contact (DC) Max Rating R Load:

  0.25A@28VDC

• Contact Voltage(DC)-Max:

  28 V

• Contact/Output Supply Type:

  DC

• Electrical Life:

  3000000 Cycle(s)

• End Contact Plating:

  GOLD

• Input Switching Control Type:

  Random

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Number of Terminals:

  6

• Operate Time:

  7 ms

• Operating Frequency-Max:

  18000 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Physical Dimension:

  12.96mm X 9.53mm X 9.78mm

• Relay Action:

  LATCHED

• Relay Form:

  1 FORM C

• Relay Function:

  SPDT

• Relay Type:

  RF RELAY

• Sealing:

  HERMETICALLY SEALED

• Surface Mount:

  NO

• Switching Time:

  7 ms

• Termination Type:

  SOLDER
