GSD090012SEU - Amphenol

GSD090012SEU Details

• Manufacturer Part Number:

  GSD090012SEU

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.40

• Manufacturer:

  Amphenol Corporation

• Board Mounting Option:

  PEG

• Body Breadth:

  0.116 inch

• Body Depth:

  1.031 inch

• Body Length:

  1.102 inch

• Connector Type:

  PCB CONNECTOR

• Contact Gender:

  FEMALE

• Contact Pattern:

  RECTANGULAR

• Contact Resistance:

  100 mΩ

• Contact Style:

  COMPRESSION

• Dielectric Withstanding Voltage:

  500VAC V

• Durability:

  10000 Cycles

• Filter Feature:

  NO

• Insertion Force-Max:

  40 N

• Insulation Resistance:

  100000000 Ω

• Insulator Color:

  IVORY

• Insulator Material:

  LIQUID CRYSTAL POLYMER

• Mating Contact Pitch:

  0.067 inch

• Mixed Contacts:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number Of PCB Rows:

  1

• Number of Rows Loaded:

  1

• Operating Temperature-Max:

  90 °C

• Operating Temperature-Min:

  -25 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  RECTANGULAR

• Plating Thickness:

  15u inch

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  0.5 A

• Reference Standard:

  UL

• Terminal Pitch:

  1.7 mm

• Termination Type:

  SURFACE MOUNT

• Total Number of Contacts:

  9

• UL Flammability Code:

  94V-0

• Withdrawl Force-Min:

  2 N
