GW12LJHC - NKK Switches

GW12LJHC Details

• Manufacturer Part Number:

  GW12LJHC

• Brand Name:

  NKK Switches

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  NKK Switches

• Actuator Angle:

  28 deg

• Actuator Color:

  CLEAR

• Actuator Length:

  0.15 inch

• Actuator Material:

  POLYCARBONATE

• Actuator Type:

  PADDLE

• Body Breadth:

  5.1562 mm

• Body Height:

  10.2108 mm

• Body Length or Diameter:

  7.0104 mm

• Center Contact Material:

  PHOSPHOR BRONZE

• Center Contact Plating:

  GOLD

• Contact (DC) Max Power Rating R Load:

  0.4VA@28VDC

• Contact Function:

  ON-ON

• Contact Resistance:

  0.08 mΩ

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  50000 Cycle(s)

• End Contact Material:

  PHOSPHOR BRONZE

• End Contact Plating:

  GOLD

• Illumination:

  LED

• Insulation Resistance:

  500000000 Ω

• Insulator Material:

  GLASS FILLED POLYAMIDE

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Operating Temperature-Max:

  55 °C

• Operating Temperature-Min:

  -25 °C

• PCB Hole Count:

  6

• Surface Mount:

  NO

• Switch Function:

  SPDT

• Switch Type:

  ROCKER SWITCH

• Terminal Finish:

  Gold (Au)

• Terminal Length:

  0.108 inch

• Terminal Material:

  PHOSPHOR BRONZE

• Termination Type:

  SOLDER
