H60SB0A050NRDC - Delta Electronics

H60SB0A050NRDC Details

• Manufacturer Part Number:

  H60SB0A050NRDC

• Part Life Cycle Code:

  Active

• Package Description:

  1/2 BRICK PACKAGE-18

• ECCN Code:

  EAR99

• Manufacturer:

  Delta Electronics Inc

• YTEOL:

  10

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CSA, EN, IEC, ISO, UL

• Efficiency (Main Output):

  98%

• Input Voltage-Max:

  60 V

• Input Voltage-Min:

  9 V

• Input Voltage-Nom:

  28 V

• JESD-30 Code:

  R-XDMA-P18

• Length:

  63.2 mm

• Load Regulation-Max:

  5.83%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  18

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  50 A

• Output Voltage-Max:

  60 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,18LEAD(UNSPEC)

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT; OVER VOLTAGE; OVER TEMPERATURE; UNDER VOLTAGE

• Ripple Voltage (Main Out):

  0.038885 Vrms

• Screening Level:

  CSA/EN/IEC/UL 62368-1

• Seated Height-Max:

  13.5 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  3000 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.03 s

• Width:

  60.6 mm
