Coilcraft provides a recommended PCB land pattern in their datasheet, but it's also available on their website as a separate document. It's essential to follow this pattern to ensure proper soldering and thermal performance.
The HA3588-BL has a maximum operating temperature of 125°C. Ensure good airflow around the inductor, and consider using a thermal pad or heat sink if the application is expected to generate high temperatures. Also, follow Coilcraft's recommended PCB layout to minimize thermal resistance.
The maximum current rating for the HA3588-BL is not explicitly stated in the datasheet. However, Coilcraft provides a current rating curve in the datasheet, which shows the inductor's current handling capability at different frequencies. Use this curve to determine the maximum current rating for your specific application.
The HA3588-BL is a surface-mount inductor, and its vibration resistance is not explicitly stated in the datasheet. However, Coilcraft's surface-mount inductors are designed to withstand moderate vibration. If your application involves extreme vibration, consider using a through-hole inductor or a surface-mount inductor with a higher vibration rating.
The HA3588-BL is designed to meet CISPR 25 Class 5 EMI requirements. To ensure EMI compliance, follow proper PCB layout and shielding techniques, and consider using additional EMI filtering components if necessary. Consult Coilcraft's application notes and EMI guidelines for more information.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
HA3588-BL Overview
Use the download button to access the HA3588-BL schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like HA358,
or try a keyword search, such as Fixed Inductors
